RESPONSIBLE FOR METADATA GDFCE (University of Sarajevo Faculty of Civil Engineering)
RESPONSIBLE AGENCY GDFCE (University of Sarajevo Faculty of Civil Engineering)
CURRENT STATION CONFIGURATION srjv00bih_20211116.log
STATUS IN EPN included since 28-11-1999
LAST AVAILABLE DATA 04-02-2023
LAST RECEIVER LEICA GR30 (06-09-2021 to now)
SET TO TRACK GPS+GLO+GAL+BDS
LAST ANTENNA LEIAR25.R4/LEIT (08-07-2019 to now)
INDIVIDUAL CALIBRATION(S) none
DATA ROUTINELY ANALYSED BY ASI, BEK, BEV, GFZ, RGA, UPA

The RINEX 2 data are no more submitted to the EPN data centres since 16-03-2022.

RINEX V2.11 - GPS+GLO+GAL
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 075/2022 N/A
BEV 075/2022 N/A
BKGE 075/2022 N/A
RINEX V3.03 - GPS+GLO+GAL+BDS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 029/2023 78.57%
BEV 035/2023 100%
BKGE 035/2023 100%
Hourly
Data centres Online Last data Availability Latency
BEV 075/2022 (A) N/A 0%
BKGE 075/2022 (A) N/A 0%
Hourly
Data centres Online Last data Availability Latency
BEV 036/2023 (G) 100% 100%
BKGE 036/2023 (G) 100% 100%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

Real-time

SRJV00BIH0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2023/02/05 00:44 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO)

    2023/02/05 00:44 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.50.274) wrt site log (4.50/7.710)

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2023/02/04 22:33 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.50.274) wrt site log (4.50/7.710)

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2023/02/05 04:18 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.50.274) wrt site log (4.50/7.710)

information above extracted from monitor files - https://epncb.eu/ftp/station/real_time/

Location

Pictures
