RESPONSIBLE FOR METADATA OS (Ordnance Survey)
RESPONSIBLE AGENCY OS (Ordnance Survey)
CURRENT STATION CONFIGURATION dare00gbr_20220614.log
STATUS IN EPN included since 27-07-2003
LAST AVAILABLE DATA 28-01-2023
LAST RECEIVER TRIMBLE ALLOY (14-06-2022 to now)
SET TO TRACK GPS+GLO+GAL+BDS+QZSS
LAST ANTENNA LEIAR10/NONE (04-10-2018 to now)
INDIVIDUAL CALIBRATION(S) none
DATA ROUTINELY ANALYSED BY IGE, MUT, ROB, WUT
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 18-02-2021.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 049/2021 N/A
BEV 049/2021 N/A
BKGE 049/2021 N/A
RINEX V3.05 - GPS+GLO+GAL+BDS+QZSS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 022/2023 78.57%
BEV 028/2023 100%
BKGE 028/2023 100%
Hourly
Data centres Online Last data Availability Latency
BEV 049/2021 (A) N/A 0%
BKGE 049/2021 (A) N/A 0%
Hourly
Data centres Online Last data Availability Latency
BEV 029/2023 (G) 100% 0%
BKGE 029/2023 (G) 100% 0%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

Real-time

DARE00GBR0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2023/01/28 18:53 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS)

    2023/01/28 18:53 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (Nav 6.14 / Boot 5.54) wrt site log (6.14)

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2023/01/28 16:39 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS)

    2023/01/28 16:39 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (Nav 6.14 / Boot 5.54) wrt site log (6.14)

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2023/01/28 21:41 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS)

    2023/01/28 21:41 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (Nav 6.14 / Boot 5.54) wrt site log (6.14)

information above extracted from monitor files - https://epncb.eu/ftp/station/real_time/
