RESPONSIBLE FOR METADATA DUT (Delft University of Technology)
RESPONSIBLE AGENCY DUT (Delft University of Technology)
CURRENT STATION CONFIGURATION dlf100nld_20201220.log
STATUS IN EPN included since 27-09-2015
LAST AVAILABLE DATA 04-02-2023
LAST RECEIVER TRIMBLE NETR9 (16-05-2020 to now)
SET TO TRACK GPS+GLO+GAL+BDS+QZSS+SBAS
LAST ANTENNA LEIAR25.R3/LEIT (15-04-2011 to now)
INDIVIDUAL CALIBRATION(S)
  • LEIAR25.R3/LEIT (SN: 10030006) from 2011-04-15 to now :
DATA ROUTINELY ANALYSED BY BKG, GFZ, LPT, ROB
INCLUSION IN OTHER NETWORK(S) IGS, EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 01-03-2022.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 059/2022 N/A
BEV 059/2022 N/A
BKGI 059/2022 N/A
RINEX V3.05 - GPS+GLO+GAL+BDS+QZSS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 029/2023 78.57%
BEV 035/2023 100%
BKGI 035/2023 100%
Hourly
Data centres Online Last data Availability Latency
BEV 060/2022 (A) N/A 0%
BKGI 060/2022 (A) N/A 0%
Hourly
Data centres Online Last data Availability Latency
BEV 036/2023 (F) 100% 100%
BKGI 036/2023 (F) 100% 100%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

Real-time

DLF100NLD0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2023/02/04 19:00 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2023/02/04 19:00 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO+GAL+BDS+QZSS)

    2023/02/04 19:00 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (5.45,06/MAR/2020) wrt site log (5.45)

    2023/02/04 19:00 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0001 m) wrt site log (0 m)

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2023/02/04 16:46 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2023/02/04 16:46 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO+GAL+BDS+QZSS)

    2023/02/04 16:46 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (5.45,06/MAR/2020) wrt site log (5.45)

    2023/02/04 16:46 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0001 m) wrt site log (0 m)

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2023/02/04 21:48 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2023/02/04 21:48 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO+GAL+BDS+QZSS)

    2023/02/04 21:48 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (5.45,06/MAR/2020) wrt site log (5.45)

    2023/02/04 21:48 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0001 m) wrt site log (0 m)

information above extracted from monitor files - https://epncb.eu/ftp/station/real_time/

Location

Pictures
