RESPONSIBLE FOR METADATA ASI (Agenzia Spaziale Italiana)
RESPONSIBLE AGENCY ASI (Agenzia Spaziale Italiana)
CURRENT STATION CONFIGURATION elba00ita_20220913.log
STATUS IN EPN included since 14-10-2001
LAST AVAILABLE DATA 28-01-2023
LAST RECEIVER LEICA GR30 (17-04-2020 to now)
SET TO TRACK GPS+GLO+GAL+BDS+SBAS
LAST ANTENNA LEIAR20/NONE (30-01-2018 to now)
INDIVIDUAL CALIBRATION(S) none
DATA ROUTINELY ANALYSED BY ASI, BEK, GFZ, RGA, UPA

The RINEX 2 data are no more submitted to the EPN data centres since 03-08-2020.

RINEX V2.11 - GPS+GLO+GAL+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 209/2020 N/A
BEV 001/2020 N/A
BKGE 209/2020 N/A
RINEX V3.04 - GPS+GLO+GAL+BDS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 022/2023 78.57%
BEV 028/2023 100%
BKGE 028/2023 100%
Hourly
Data centres Online Last data Availability Latency
BEV 209/2020 (U) N/A 0%
BKGE 209/2020 (T) N/A 0%
Hourly
Data centres Online Last data Availability Latency
BEV 029/2023 (H) 100% 98.21%
BKGE 029/2023 (H) 100% 98.81%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

Real-time

ELBA00ITA0 :

  • ASI (broadcaster, registration) - RTCM 3.1 : GPS+GLO

    2023/01/28 19:17 RTCM 3.1 : Unexpected constellations in stream (GPS+GLO) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2023/01/28 19:17 RTCM 3.1/1033: Incorrect Receiver Firmware Version in stream (4.35.173) wrt site log (4.35/7.504)

  • BKG (broadcaster, registration) - RTCM 3.1 : GPS+GLO

    2023/01/28 17:02 RTCM 3.1 : Unexpected constellations in stream (GPS+GLO) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2023/01/28 17:02 RTCM 3.1/1033: Incorrect Receiver Firmware Version in stream (4.35.173) wrt site log (4.35/7.504)

  • ROB (broadcaster, registration) - RTCM 3.1 : GPS+GLO

    2023/01/28 22:05 RTCM 3.1 : Unexpected constellations in stream (GPS+GLO) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2023/01/28 22:05 RTCM 3.1/1033: Incorrect Receiver Firmware Version in stream (4.35.173) wrt site log (4.35/7.504)

information above extracted from monitor files - https://epncb.eu/ftp/station/real_time/
