RESPONSIBLE AGENCY GKU (Geodetic and Cartographic Institute Bratislava)
RESPONSIBLE FOR METADATA GKU (Geodetic and Cartographic Institute Bratislava)
CURRENT STATION CONFIGURATION ganp00svk_20240111.log
STATUS IN EPN included since 16-11-2003
LAST AVAILABLE DATA 29-02-2024
LAST RECEIVER TRIMBLE ALLOY (09-01-2024 to now)
SET TO TRACK GPS+GLO+GAL+BDS+QZSS+IRNSS+SBAS
LAST ANTENNA TRM59800.00/SCIS (06-02-2017 to now)
INDIVIDUAL CALIBRATION(S)
  • TRM55971.00/NONE (SN: 30137385) from 2006-08-24 to 2017-02-06 :
  • TRM59800.00/SCIS (SN: 5620361622) from 2017-02-06 to now :
DATA ROUTINELY ANALYSED BY COD, SGO, SUT, WUT
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 01-04-2020.

RINEX V2.11 - GPS+GLO+GAL+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 091/2020 N/A
BEV 023/2020 N/A
BKGI 091/2020 N/A
RINEX V3.05 - GPS+GLO+GAL+BDS+QZSS+IRNSS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 054/2024 78.57%
BEV 060/2024 100%
BKGI 058/2024 92.86%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 061/2024 (K) 100% 70.83%
BKGI 061/2024 (K) 100% 55.36%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

Real-time

GANP00SVK0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2024/02/29 20:04 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2024/02/29 20:04 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO)

    2024/02/29 20:04 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (Nav 6.23 / Boot 5.63) wrt site log (6.23)

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2024/02/29 17:57 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2024/02/29 17:57 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (Nav 6.23 / Boot 5.63) wrt site log (6.23)

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2024/02/29 22:58 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2024/02/29 22:58 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO+GAL+BDS+QZSS)

    2024/02/29 22:58 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (Nav 6.23 / Boot 5.63) wrt site log (6.23)

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

Location

Pictures
