RESPONSIBLE AGENCY GOP (Geodetic Observatory Pecny, RIGTC)
RESPONSIBLE FOR METADATA GOP (Geodetic Observatory Pecny, RIGTC)
CURRENT STATION CONFIGURATION gop600cze_20230925.log
STATUS IN EPN included since 05-07-2015
LAST AVAILABLE DATA 29-02-2024
LAST RECEIVER SEPT POLARX5 (25-09-2023 to now)
SET TO TRACK GPS+GLO+GAL+BDS+QZSS+IRNSS+SBAS
LAST ANTENNA SEPCHOKE_B3E6/SPKE (09-04-2019 to now)
INDIVIDUAL CALIBRATION(S)
  • LEIAR25.R4/LEIT (SN: 725071) from 2011-12-21 to 2012-04-10, from 2012-04-10 to 2019-04-09 :
  • SEPCHOKE_B3E6/SPKE (SN: 5287) from 2019-04-09 to now :
DATA ROUTINELY ANALYSED BY BEV, BKG, GFZ, LPT, SUT
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 16-03-2022.

RINEX V2.11 - GPS+GLO+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 074/2022 N/A
BEV 074/2022 N/A
BKGI 074/2022 N/A
RINEX V4.00 - GPS+GLO+GAL+BDS+QZSS+IRNSS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 054/2024 78.57%
BEV 060/2024 100%
BKGI 060/2024 100%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 061/2024 (J) 99.4% 93.45%
BKGI 061/2024 (K) 98.21% 84.52%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

Real-time

GOP600CZE0 :

  • ASI (broadcaster, registration) - RTCM 3.3 : GPS+GLO+GAL+BDS+QZSS+SBAS (MSM7)

    2024/02/29 20:13 RTCM 3.3 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS+SBAS) wrt source table (GPS+GLO)

    2024/02/29 20:13 RTCM 3.3/1006: Incorrect Antenna Height in stream (0.0650 m) wrt site log (0.0653 m)

  • BKG (broadcaster, registration) - RTCM 3.3 : GPS+GLO+GAL+BDS+QZSS+SBAS (MSM7)

    2024/02/29 18:05 RTCM 3.3/1006: Incorrect Antenna Height in stream (0.0650 m) wrt site log (0.0653 m)

  • ROB (broadcaster, registration) - RTCM 3.3 : GPS+GLO+GAL+BDS+QZSS+SBAS (MSM7)

    2024/02/29 23:07 RTCM 3.3/1006: Incorrect Antenna Height in stream (0.0650 m) wrt site log (0.0653 m)

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

Location

Pictures
