RESPONSIBLE FOR METADATA NSGF (NERC Space Geodesy Facility)
RESPONSIBLE AGENCY NSGF (NERC Space Geodesy Facility)
CURRENT STATION CONFIGURATION hers00gbr_20220913.log
STATUS IN EPN included since 14-01-1996
LAST AVAILABLE DATA 28-01-2023
LAST RECEIVER SEPT POLARX5TR (08-02-2021 to now)
SET TO TRACK GPS+GLO+GAL+BDS+SBAS
LAST ANTENNA LEIAR25.R3/NONE (19-08-2010 to now)
INDIVIDUAL CALIBRATION(S) none
DATA ROUTINELY ANALYSED BY BKG, GFZ, IGE, MUT, NKG, ROB
INCLUSION IN OTHER NETWORK(S) IGS, EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 17-03-2022.

RINEX V2.11 - GPS+GLO+GAL+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 075/2022 N/A
BEV 075/2022 N/A
BKGI 075/2022 N/A
RINEX V3.04 - GPS+GLO+GAL+BDS+IRNSS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 022/2023 78.57%
BEV 028/2023 100%
BKGI 028/2023 100%
Hourly
Data centres Online Last data Availability Latency
BEV 076/2022 (A) N/A 0%
BKGI 076/2022 (A) N/A 0%
Hourly
Data centres Online Last data Availability Latency
BEV 029/2023 (H) 98.81% 98.81%
BKGI 029/2023 (H) 100% 100%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

Real-time

HERS00GBR0 :

  • BKG (broadcaster, registration) - RTCM 3.3 : GPS+GLO+GAL+BDS+QZSS+SBAS (MSM7)

    2023/01/28 17:56 RTCM 3.3 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS+SBAS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2023/01/28 17:56 RTCM 3.3/1006: Coordinate difference with ETRS89 ( 0.1290 m) exceeds threshold

  • ROB (broadcaster, registration) - RTCM 3.3 : GPS+GLO+GAL+BDS+QZSS+SBAS (MSM7)

    2023/01/28 23:01 RTCM 3.3 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS+SBAS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2023/01/28 23:01 RTCM 3.3/1006: Coordinate difference with ETRS89 ( 0.1290 m) exceeds threshold

information above extracted from monitor files - https://epncb.eu/ftp/station/real_time/

Location

Pictures
