RESPONSIBLE FOR METADATA DUT (Delft University of Technology)
RESPONSIBLE AGENCY KAD (Kadaster)
CURRENT STATION CONFIGURATION ijmu00nld_20220609.log
STATUS IN EPN included since 29-05-2016
LAST AVAILABLE DATA 28-01-2023
LAST RECEIVER TRIMBLE NETR9 (09-06-2022 to now)
SET TO TRACK GPS+GLO+GAL+BDS+QZSS+SBAS
LAST ANTENNA LEIAR25.R4/LEIT (23-04-2014 to now)
INDIVIDUAL CALIBRATION(S)
  • LEIAR25.R4/LEIT (SN: 726702) from 2014-04-23 to now :
  • TRM29659.00/UNAV (SN: 0220314044) from 2004-12-30 to 2014-04-23 :
DATA ROUTINELY ANALYSED BY BKG, ROB, WUT
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 01-03-2022.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 059/2022 N/A
BEV 059/2022 N/A
BKGE 059/2022 N/A
RINEX V3.04 - GPS+GLO+GAL+BDS+QZSS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 022/2023 78.57%
BEV 028/2023 100%
BKGE 028/2023 100%
Hourly
Data centres Online Last data Availability Latency
BEV 060/2022 (A) N/A 0%
BKGE 060/2022 (A) N/A 0%
Hourly
Data centres Online Last data Availability Latency
BEV 029/2023 (H) 100% 99.4%
BKGE 029/2023 (H) 100% 100%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

Real-time

IJMU00NLD0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2023/01/28 20:26 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2023/01/28 20:26 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO+GAL+BDS+QZSS)

    2023/01/28 20:26 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (5.54,25/MAR/2022) wrt site log (5.54)

    2023/01/28 20:26 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0001 m) wrt site log (0 m)

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2023/01/28 18:20 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2023/01/28 18:20 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO+GAL+BDS+QZSS)

    2023/01/28 18:20 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (5.54,25/MAR/2022) wrt site log (5.54)

    2023/01/28 18:20 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0001 m) wrt site log (0 m)

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2023/01/28 23:32 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2023/01/28 23:32 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO+GAL+BDS+QZSS)

    2023/01/28 23:32 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (5.54,25/MAR/2022) wrt site log (5.54)

    2023/01/28 23:32 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0001 m) wrt site log (0 m)

information above extracted from monitor files - https://epncb.eu/ftp/station/real_time/
