RESPONSIBLE AGENCY LMV (Lantmäteriet, the Swedish mapping, cadastral and land registration authority)
RESPONSIBLE FOR METADATA LMV (Lantmäteriet, the Swedish mapping, cadastral and land registration authority)
CURRENT STATION CONFIGURATION kir800swe_20221207.log
STATUS IN EPN included since 31-01-2016
DATA LICENSE CC-BY-4.0
LAST AVAILABLE DATA 08-11-2024
LAST RECEIVER TRIMBLE ALLOY (07-12-2022 to now)
SET TO TRACK GPS+GLO+GAL+BDS+QZSS+SBAS
LAST ANTENNA LEIAR25.R3/LEIT (12-08-2011 to now)
INDIVIDUAL CALIBRATION(S)
  • LEIAR25.R3/LEIT (SN: 09030016) from 2011-08-12 to now :
DATA ROUTINELY ANALYSED BY BEV, MUT, NKG, WUT
INCLUSION IN OTHER NETWORK(S) IGS, EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 28-04-2020.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 118/2020 N/A
BEV 023/2020 N/A
BKGI 118/2020 N/A
RINEX V3.04 - GPS+GLO+GAL+BDS+QZSS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 307/2024 78.57%
BEV 313/2024 100%
BKGI 313/2024 100%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 314/2024 (N) 100% 75.6%
BKGI 314/2024 (N) 100% 97.62%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page

BKG upload settings to other data centres.

Real-time

KIR800SWE0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS+QZSS (MSM5)

    2024/11/09 14:08 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2024/11/09 14:08 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS) wrt source table (GPS+GLO)

    2024/11/09 14:08 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (6.15,22/JUL/2022) wrt site log (6.15)

    2024/11/09 14:08 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0001 m) wrt site log (0.0030 m)

    2024/11/09 14:08 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.1621 m) exceeds threshold

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS+QZSS (MSM5)

    2024/11/09 11:01 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2024/11/09 11:01 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (6.15,22/JUL/2022) wrt site log (6.15)

    2024/11/09 11:01 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0001 m) wrt site log (0.0030 m)

    2024/11/09 11:01 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.1621 m) exceeds threshold

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS+QZSS (MSM5)

    2024/11/09 12:20 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2024/11/09 12:20 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (6.15,22/JUL/2022) wrt site log (6.15)

    2024/11/09 12:20 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0001 m) wrt site log (0.0030 m)

    2024/11/09 12:20 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.1621 m) exceeds threshold

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/
