RESPONSIBLE FOR METADATA GOP (Geodetic Observatory Pecny, RIGTC)
RESPONSIBLE AGENCY GOP (Geodetic Observatory Pecny, RIGTC)
CURRENT STATION CONFIGURATION kunz00cze_20200715.log
STATUS IN EPN included since 12-12-2010
LAST AVAILABLE DATA 04-02-2023
LAST RECEIVER TRIMBLE SPS855 (15-05-2018 to now)
SET TO TRACK GPS+GLO+GAL+BDS+SBAS
LAST ANTENNA TRM57971.00/NONE (08-07-2016 to now)
INDIVIDUAL CALIBRATION(S)
  • TRM41249.00/TZGD (SN: 12379170) from 2006-10-05 to 2014-09-09 :
  • TRM57971.00/NONE (SN: 5000118141) from 2014-09-09 to 2016-07-08, from 2016-07-08 to now :
DATA ROUTINELY ANALYSED BY BEV, MUT, RGA, SUT, WUT
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 16-03-2022.

RINEX V2.11 - GPS+GLO+GAL+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 074/2022 N/A
BEV 074/2022 N/A
BKGE 074/2022 N/A
RINEX V3.03 - GPS+GLO+GAL+BDS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 029/2023 78.57%
BEV 035/2023 100%
BKGE 035/2023 100%
Hourly
Data centres Online Last data Availability Latency
BEV 075/2022 (A) N/A 0%
BKGE 075/2022 (A) N/A 0%
Hourly
Data centres Online Last data Availability Latency
BEV 036/2023 (H) 100% 97.02%
BKGE 036/2023 (H) 100% 97.02%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

Real-time

KUNZ00CZE0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM4)

    2023/02/04 21:14 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2023/02/04 21:14 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO+GAL+BDS+QZSS)

    2023/02/04 21:14 RTCM 3.2/1008: Incorrect Antenna-Radome type in stream (TRM55971.00 NONE 5000118141) wrt site log (TRM57971.00 NONE)

    2023/02/04 21:14 RTCM 3.2/1033: Incorrect Antenna-Radome type/SN (TRM55971.00 NONE 5000118141) wrt site log (TRM57971.00 NONE 5000118141)

    2023/02/04 21:14 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (5.32,15/DEC/2017) wrt site log (5.32)

    2023/02/04 21:14 RTCM 3.2/1033: Incorrect Receiver SN in stream (5327K44098) wrt site log (44098)

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM4)

    2023/02/04 19:08 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2023/02/04 19:08 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO+GAL+BDS+QZSS)

    2023/02/04 19:08 RTCM 3.2/1008: Incorrect Antenna-Radome type in stream (TRM55971.00 NONE 5000118141) wrt site log (TRM57971.00 NONE)

    2023/02/04 19:08 RTCM 3.2/1033: Incorrect Antenna-Radome type/SN (TRM55971.00 NONE 5000118141) wrt site log (TRM57971.00 NONE 5000118141)

    2023/02/04 19:08 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (5.32,15/DEC/2017) wrt site log (5.32)

    2023/02/04 19:08 RTCM 3.2/1033: Incorrect Receiver SN in stream (5327K44098) wrt site log (44098)

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM4)

    2023/02/05 00:42 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2023/02/05 00:42 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO+GAL+BDS+QZSS)

    2023/02/05 00:42 RTCM 3.2/1008: Incorrect Antenna-Radome type in stream (TRM55971.00 NONE 5000118141) wrt site log (TRM57971.00 NONE)

    2023/02/05 00:42 RTCM 3.2/1033: Incorrect Antenna-Radome type/SN (TRM55971.00 NONE 5000118141) wrt site log (TRM57971.00 NONE 5000118141)

    2023/02/05 00:42 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (5.32,15/DEC/2017) wrt site log (5.32)

    2023/02/05 00:42 RTCM 3.2/1033: Incorrect Receiver SN in stream (5327K44098) wrt site log (44098)

information above extracted from monitor files - https://epncb.eu/ftp/station/real_time/

Location

Pictures
