RESPONSIBLE FOR METADATA IGE (Instituto Geografico Nacional de Espana)
RESPONSIBLE AGENCY IGE (Instituto Geografico Nacional de Espana)
CURRENT STATION CONFIGURATION mala00esp_20220907.log
STATUS IN EPN included since 13-11-2005
LAST AVAILABLE DATA 04-02-2023
LAST RECEIVER LEICA GR25 (07-04-2021 to now)
SET TO TRACK GPS+GLO+GAL
LAST ANTENNA LEIAR25.R4/LEIT (13-03-2013 to now)
INDIVIDUAL CALIBRATION(S)
  • LEIAR25.R4/LEIT (SN: 725494) from 2013-03-13 to now :
DATA ROUTINELY ANALYSED BY BEK, IGE, MUT, WUT
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 02-12-2020.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 335/2020 N/A
BEV 001/2020 N/A
BKGE 335/2020 N/A
RINEX V3.04 - GPS+GLO+GAL
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 029/2023 78.57%
BEV 035/2023 96.43%
BKGE 035/2023 96.43%
Hourly
Data centres Online Last data Availability Latency
BEV 336/2020 (S) N/A 0%
BKGE 336/2020 (S) N/A 0%
Hourly
Data centres Online Last data Availability Latency
BEV 036/2023 (G) 99.4% 98.81%
BKGE 036/2023 (G) 99.4% 98.81%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

Real-time

MALA00ESP0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL (MSM5)

    2023/02/04 21:44 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL) wrt source table (GPS+GLO)

    2023/02/04 21:44 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (3.22.1818) wrt site log (3.22/6.713)

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL (MSM5)

    2023/02/04 19:44 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (3.22.1818) wrt site log (3.22/6.713)

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL (MSM5)

    2023/02/05 01:23 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (3.22.1818) wrt site log (3.22/6.713)

information above extracted from monitor files - https://epncb.eu/ftp/station/real_time/

Location

Pictures
