RESPONSIBLE AGENCY IGE (Instituto Geografico Nacional de Espana)
RESPONSIBLE FOR METADATA IGE (Instituto Geografico Nacional de Espana)
CURRENT STATION CONFIGURATION mall00esp_20230725.log
STATUS IN EPN included since 21-01-2001
LAST AVAILABLE DATA 29-02-2024
LAST RECEIVER LEICA GR50 (25-07-2023 to now)
SET TO TRACK GPS+GLO+GAL+BDS
LAST ANTENNA LEIAR20/LEIM (18-05-2022 to now)
INDIVIDUAL CALIBRATION(S)
  • LEIAR20/LEIM (SN: 24243015) from 2022-05-18 to now :
DATA ROUTINELY ANALYSED BY BKG, IGE, IGN, MUT
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 02-12-2020.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 333/2020 N/A
BEV 316/2020 N/A
BKGE 333/2020 N/A
RINEX V3.04 - GPS+GLO+GAL+BDS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 054/2024 78.57%
BEV 060/2024 100%
BKGE 060/2024 100%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 061/2024 (K) 98.81% 98.81%
BKGE 061/2024 (K) 100% 89.88%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

Real-time

MALL00ESP0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7) : stream temporarily unavailable

    2024/02/29 22:24 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO)

    2024/02/29 22:24 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.70.040) wrt site log (4.70/7.813)

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7) : stream temporarily unavailable

    2024/02/29 20:21 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.70.040) wrt site log (4.70/7.813)

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7) : stream temporarily unavailable

    2024/03/01 01:22 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.70.040) wrt site log (4.70/7.813)

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

Location

Pictures
