EUREF Permanent GNSS Network

Station Configuration

RESPONSIBLE AGENCY	IGE (Instituto Geografico Nacional de Espana)
RESPONSIBLE FOR METADATA	IGE (Instituto Geografico Nacional de Espana)
CURRENT STATION CONFIGURATION	meli00esp_20240319.log
STATUS IN EPN	included since 12-08-2012
DATA LICENSE	CC-BY-4.0
DIGITAL OBJECT IDENTIFIER (DOI)	https://doi.org/10.24414/ROB-EUREF-MELI00ESP
LAST AVAILABLE DATA	01-07-2024
LAST RECEIVER	LEICA GR50 (19-03-2024 to now)
SET TO TRACK	GPS+GLO+GAL+BDS
LAST ANTENNA	LEIAR25.R4/LEIT (14-12-2011 to now)
INDIVIDUAL CALIBRATION(S)	LEIAR25.R4/LEIT (SN: 725140) from 2011-12-14 to now : GEO - ROBOT (freq: G01, G02, R01, R02, date: 2011-08-04)
DATA ROUTINELY ANALYSED BY	ASI, BKG, IGE, IGN
INCLUSION IN OTHER NETWORK(S)	IGS, EPOS

Data Provided

The RINEX 2 data are no more submitted to the EPN data centres since 02-12-2020.

No recent data available

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

MELI00ESP0 :

ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)
2024/07/02 22:56 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO)
2024/07/02 22:56 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.80.109) wrt site log (4.80/7.900)
2024/07/02 22:56 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0606 m) wrt site log (0.21957 m)

BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)
2024/07/02 20:49 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.80.109) wrt site log (4.80/7.900)
2024/07/02 20:49 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0606 m) wrt site log (0.21957 m)

ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)
2024/07/02 01:47 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.80.109) wrt site log (4.80/7.900)
2024/07/02 01:47 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0606 m) wrt site log (0.21957 m)

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

RINEX Data Quality

Daily tracking performances

Monthly snapshots of satellite tracking

Position, Velocity & Time Series

EUREF is providing positions and velocities for the station MELI00ESP
Last ETRF2000 position valid from 354/2011 to 316/2022 expressed at epoch 001/2010
X = 5205628.385 m	Vx = -0.0025 m/y
Y = -268411.236 m	Vy = -0.0033 m/y
Z = 3663428.126 m	Vz = 0.0011 m/y
