RESPONSIBLE FOR METADATA SUT (Slovak University of Technology)
RESPONSIBLE AGENCY SUT (Slovak University of Technology)
CURRENT STATION CONFIGURATION mop200svk_20221213.log
STATUS IN EPN included since 24-08-2008
LAST AVAILABLE DATA 04-02-2023
LAST RECEIVER TRIMBLE NETR9 (13-12-2022 to now)
SET TO TRACK GPS+GLO+GAL+BDS+QZSS
LAST ANTENNA TRM55971.00/NONE (24-05-2020 to now)
INDIVIDUAL CALIBRATION(S)
  • TRM55971.00/TZGD (SN: 30477181) from 2007-10-05 to 2020-05-23 :
DATA ROUTINELY ANALYSED BY BEV, LPT, SGO, SUT, WUT
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 06-04-2020.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 097/2020 N/A
BEV 001/2020 N/A
BKGE 097/2020 N/A
RINEX V3.05 - GPS+GLO+GAL+BDS+QZSS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 029/2023 78.57%
BEV 035/2023 100%
BKGE 035/2023 100%
Hourly
Data centres Online Last data Availability Latency
BEV 097/2020 (A) N/A 0%
BKGE 097/2020 (A) N/A 0%
Hourly
Data centres Online Last data Availability Latency
BEV 036/2023 (G) 100% 100%
BKGE 036/2023 (G) 100% 100%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

Real-time

MOP200SVK0 :

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2023/02/04 20:25 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS)

    2023/02/04 20:25 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (Nav 5.56 / Boot 5.56) wrt site log (5.56)

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2023/02/05 02:08 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS)

    2023/02/05 02:08 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO+GAL+BDS+QZSS)

    2023/02/05 02:08 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (Nav 5.56 / Boot 5.56) wrt site log (5.56)

information above extracted from monitor files - https://epncb.eu/ftp/station/real_time/

Location

Pictures
