RESPONSIBLE AGENCY LUAI (Institute of Astronomy University of Latvia)
RESPONSIBLE FOR METADATA LUAI (Institute of Astronomy University of Latvia)
CURRENT STATION CONFIGURATION riga00lva_20240507.log
STATUS IN EPN included since 03-11-1996
DATA LICENSE CC-BY-4.0
LAST AVAILABLE DATA 05-11-2024
LAST RECEIVER LEICA GR25 (04-04-2024 to now)
SET TO TRACK GPS+GLO+GAL+BDS+SBAS
LAST ANTENNA LEIAR25.R4/LEIT (11-12-2013 to now)
INDIVIDUAL CALIBRATION(S)
  • AOAD/M_T/NONE (SN: 519) from 1995-12-05 to 1996-03-28 :
  • LEIAR25.R4/LEIT (SN: 726676) from 2013-12-11 to now :
DATA ROUTINELY ANALYSED BY BEV, NKG, SUT, WUT
INCLUSION IN OTHER NETWORK(S) IGS, EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 07-03-2023.

RINEX V2.11 - GPS+GLO+GAL+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 066/2023 N/A
BEV 066/2023 N/A
BKGI 066/2023 N/A
RINEX V3.04 - GPS+GLO+GAL+BDS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 307/2024 78.57%
BEV 310/2024 89.29%
BKGI 310/2024 89.29%
Hourly
Data centres Online Last data Availability Latency
BEV 066/2023 (A) N/A 0%
BKGI 066/2023 (A) N/A 0%
Hourly
Data centres Online Last data Availability Latency
BEV 314/2024 (L) 100% 75%
BKGI 314/2024 (L) 100% 77.98%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page

BKG upload settings to other data centres.

Real-time

RIGA00LVA0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2024/11/08 16:47 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2024/11/08 16:47 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.80.109) wrt site log (4.80/6.525)

    2024/11/08 16:47 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.2433 m) exceeds threshold

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2024/11/08 13:56 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2024/11/08 13:56 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.80.109) wrt site log (4.80/6.525)

    2024/11/08 13:56 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.2433 m) exceeds threshold

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2024/11/08 15:25 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2024/11/08 15:25 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.80.109) wrt site log (4.80/6.525)

    2024/11/08 15:25 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.2433 m) exceeds threshold

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

Location

Pictures
