RESPONSIBLE FOR METADATA LMV (Lantmäteriet, the Swedish mapping, cadastral and land registration authority)
RESPONSIBLE AGENCY LMV (Lantmäteriet, the Swedish mapping, cadastral and land registration authority)
CURRENT STATION CONFIGURATION spt700swe_20201111.log
STATUS IN EPN included since 26-06-2022
LAST AVAILABLE DATA 04-02-2023
LAST RECEIVER TRIMBLE ALLOY (29-11-2022 to now)
SET TO TRACK GPS+GLO+GAL+BDS+SBAS
LAST ANTENNA LEIAR25.R3/LEIT (07-10-2011 to now)
INDIVIDUAL CALIBRATION(S)
  • LEIAR25.R3/LEIT (SN: 08520001) from 2011-10-07 to now :
DATA ROUTINELY ANALYSED BY MUT, NKG, ROB, SUT
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 18-03-2022.

RINEX V2.11
Daily
(data calendar)

No recent data available

RINEX V3.04 - GPS+GLO+GAL+BDS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 029/2023 78.57%
BEV 035/2023 100%
BKGE 035/2023 100%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 036/2023 (H) 100% 99.4%
BKGE 036/2023 (H) 100% 100%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

Real-time

SPT700SWE0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2023/02/05 00:41 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2023/02/05 00:41 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO+GAL+BDS+QZSS)

    2023/02/05 00:41 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (6.15,22/JUL/2022) wrt site log (6.15)

    2023/02/05 00:41 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0001 m) wrt site log (0.003 m)

    2023/02/05 00:41 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.0790 m) exceeds threshold

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2023/02/04 22:30 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2023/02/04 22:30 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (6.15,22/JUL/2022) wrt site log (6.15)

    2023/02/04 22:30 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0001 m) wrt site log (0.003 m)

    2023/02/04 22:30 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.0790 m) exceeds threshold

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2023/02/05 04:15 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2023/02/05 04:15 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (6.15,22/JUL/2022) wrt site log (6.15)

    2023/02/05 04:15 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0001 m) wrt site log (0.003 m)

    2023/02/05 04:15 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.0790 m) exceeds threshold

information above extracted from monitor files - https://epncb.eu/ftp/station/real_time/

Location

Pictures
