RESPONSIBLE FOR METADATA DUT (Delft University of Technology)
RESPONSIBLE AGENCY KAD (Kadaster)
CURRENT STATION CONFIGURATION ters00nld_20221125.log
STATUS IN EPN included since 20-06-1999
LAST AVAILABLE DATA 04-02-2023
LAST RECEIVER SEPT POLARX5E (25-11-2022 to now)
SET TO TRACK GPS+GLO+GAL+BDS+QZSS+IRNSS+SBAS
LAST ANTENNA LEIAR25.R4/LEIT (20-11-2020 to now)
INDIVIDUAL CALIBRATION(S)
  • LEIAR25.R4/LEIT (SN: 726700) from 2014-06-07 to 2020-11-20, from 2020-11-20 to now :
DATA ROUTINELY ANALYSED BY COE, GFZ, LPT, MUT, ROB
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 01-03-2022.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 059/2022 N/A
BEV 059/2022 N/A
BKGE 059/2022 N/A
RINEX V3.04 - GPS+GLO+GAL+BDS+QZSS+IRNSS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 029/2023 75%
BEV 035/2023 96.43%
BKGE 035/2023 96.43%
Hourly
Data centres Online Last data Availability Latency
BEV 060/2022 (A) N/A 0%
BKGE 060/2022 (A) N/A 0%
Hourly
Data centres Online Last data Availability Latency
BEV 036/2023 (H) 100% 97.62%
BKGE 036/2023 (H) 100% 100%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

Real-time

TERS00NLD0 :

  • ASI (broadcaster, registration) - RTCM 3.3 : GPS+GLO+GAL+BDS+QZSS+SBAS (MSM7)

    2023/02/05 01:15 RTCM 3.3 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS+SBAS) wrt source table (GPS+GLO+GAL+BDS+QZSS)

information above extracted from monitor files - https://epncb.eu/ftp/station/real_time/

Location

Pictures
