RESPONSIBLE AGENCY BKG (Bundesamt fuer Kartographie und Geodaesie)
RESPONSIBLE FOR METADATA BKG (Bundesamt fuer Kartographie und Geodaesie)
CURRENT STATION CONFIGURATION baut00deu_20240215.log
STATUS IN EPN included since 05-05-2019
LAST AVAILABLE DATA 29-02-2024
LAST RECEIVER JAVAD TRE_3 DELTA (15-02-2024 to now)
SET TO TRACK GPS+GLO+GAL+BDS+SBAS
LAST ANTENNA LEIAR25.R3/LEIT (17-02-2021 to now)
INDIVIDUAL CALIBRATION(S)
  • LEIAR25.R3/LEIT (SN: 10020025) from 2021-02-17 to now :
  • LEIAR25.R4/LEIT (SN: 725267) from 2018-09-26 to 2021-02-17 :
DATA ROUTINELY ANALYSED BY ASI, BEK, BKG, GFZ
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 03-05-2021.

RINEX V2.11 - GPS+GLO+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 123/2021 N/A
BEV 123/2021 N/A
BKGI 123/2021 N/A
RINEX V3.05 - GPS+GLO+GAL+BDS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 054/2024 75%
BEV 060/2024 100%
BKGI 060/2024 96.43%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 061/2024 (J) 100% 100%
BKGI 061/2024 (J) 100% 90.48%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

Real-time

BAUT00DEU0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2024/02/29 17:39 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2024/02/29 17:39 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO+SBAS)

    2024/02/29 17:39 RTCM 3.2/1033: Incorrect Receiver SN in stream (0SC0F38PEWI7L0QDSPVJ) wrt site log (02812)

    2024/02/29 17:39 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.8417 m) exceeds threshold

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2024/02/29 15:26 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2024/02/29 15:26 RTCM 3.2/1033: Incorrect Receiver SN in stream (0SC0F38PEWI7L0QDSPVJ) wrt site log (02812)

    2024/02/29 15:26 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.8417 m) exceeds threshold

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2024/02/29 20:27 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2024/02/29 20:27 RTCM 3.2/1033: Incorrect Receiver SN in stream (0SC0F38PEWI7L0QDSPVJ) wrt site log (02812)

    2024/02/29 20:27 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.8417 m) exceeds threshold

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

Location

Pictures
