RESPONSIBLE AGENCY IGE (Instituto Geografico Nacional de Espana)
RESPONSIBLE FOR METADATA IGE (Instituto Geografico Nacional de Espana)
CURRENT STATION CONFIGURATION bcln00esp_20230720.log
STATUS IN EPN included since 02-08-2015
LAST AVAILABLE DATA 19-04-2024
LAST RECEIVER LEICA GR10 (18-07-2023 to now)
SET TO TRACK GPS+GLO+GAL
LAST ANTENNA LEIAR25.R4/LEIT (31-01-2012 to now)
INDIVIDUAL CALIBRATION(S)
  • LEIAR25.R4/LEIT (SN: 725229) from 2012-01-31 to now :
DATA ROUTINELY ANALYSED BY ASI, BEK, IGE, ROB
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 02-12-2020.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 335/2020 N/A
BEV 316/2020 N/A
BKGE 335/2020 N/A
RINEX V3.04 - GPS+GLO+GAL
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 104/2024 78.57%
BEV 110/2024 100%
BKGE 110/2024 100%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 111/2024 (F) 100% 100%
BKGE 111/2024 (F) 100% 100%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

Real-time

BCLN00ESP0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL (MSM5)

    2024/04/19 17:42 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL) wrt source table (GPS+GLO)

    2024/04/19 17:42 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.70.040) wrt site log (4.70/6.525)

    2024/04/19 17:42 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0776 m) wrt site log (0.23657 m)

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL (MSM5)

    2024/04/19 15:30 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.70.040) wrt site log (4.70/6.525)

    2024/04/19 15:30 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0776 m) wrt site log (0.23657 m)

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL (MSM5)

    2024/04/19 20:29 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.70.040) wrt site log (4.70/6.525)

    2024/04/19 20:29 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0776 m) wrt site log (0.23657 m)

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/
