RESPONSIBLE AGENCY BKG (Bundesamt fuer Kartographie und Geodaesie)
RESPONSIBLE FOR METADATA BKG (Bundesamt fuer Kartographie und Geodaesie)
CURRENT STATION CONFIGURATION borj00deu_20240215.log
STATUS IN EPN included since 24-12-2006
LAST AVAILABLE DATA 19-04-2024
LAST RECEIVER JAVAD TRE_3 DELTA (15-02-2024 to now)
SET TO TRACK GPS+GLO+GAL+BDS+SBAS
LAST ANTENNA LEIAR25.R4/LEIT (02-08-2022 to now)
INDIVIDUAL CALIBRATION(S)
  • LEIAR25.R3/LEIT (SN: 08500021) from 2010-09-01 to 2018-04-25 :
  • LEIAR25.R4/LEIT (SN: 726363) from 2018-04-25 to 2022-08-02 :
  • LEIAR25.R4/LEIT (SN: 727331) from 2022-08-02 to now :
  • TPSCR3_GGD/CONE (SN: 2170182) from 2005-06-09 to 2010-09-01 :
DATA ROUTINELY ANALYSED BY BKG, LPT, MUT, ROB
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 02-11-2021.

RINEX V2.11 - GPS+GLO+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 305/2021 N/A
BEV 305/2021 N/A
BKGE 305/2021 N/A
RINEX V3.05 - GPS+GLO+GAL+BDS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 104/2024 78.57%
BEV 109/2024 96.43%
BKGE 110/2024 100%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 111/2024 (G) 100% 100%
BKGE 111/2024 (G) 100% 100%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

Real-time

BORJ00DEU0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2024/04/19 17:52 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2024/04/19 17:52 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO)

    2024/04/19 17:52 RTCM 3.2/1033: Incorrect Receiver SN in stream (1QBT2677ZQGXI0QYWF01) wrt site log (02044)

    2024/04/19 17:52 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0450 m) wrt site log (0.20397 m)

    2024/04/19 17:52 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.7496 m) exceeds threshold

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2024/04/19 15:39 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2024/04/19 15:39 RTCM 3.2/1033: Incorrect Receiver SN in stream (1QBT2677ZQGXI0QYWF01) wrt site log (02044)

    2024/04/19 15:39 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0450 m) wrt site log (0.20397 m)

    2024/04/19 15:39 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.7496 m) exceeds threshold

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2024/04/19 20:39 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2024/04/19 20:39 RTCM 3.2/1033: Incorrect Receiver SN in stream (1QBT2677ZQGXI0QYWF01) wrt site log (02044)

    2024/04/19 20:39 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0450 m) wrt site log (0.20397 m)

    2024/04/19 20:39 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.7496 m) exceeds threshold

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

Location

Pictures
