RESPONSIBLE AGENCY ROB (Royal Observatory of Belgium)
RESPONSIBLE FOR METADATA ROB (Royal Observatory of Belgium)
CURRENT STATION CONFIGURATION brux00bel_20230124.log
STATUS IN EPN included since 11-03-2012
DATA LICENSE CC-BY-4.0
DIGITAL OBJECT IDENTIFIER (DOI) https://doi.org/10.24414/ROB-GNSS-BRUX00BEL
LAST AVAILABLE DATA 08-10-2024
LAST RECEIVER SEPT POLARX5TR (11-10-2022 to now)
SET TO TRACK GPS+GLO+GAL+BDS+QZSS+IRNSS+SBAS
LAST ANTENNA JAVRINGANT_DM/SCIS (20-04-2021 to now)
INDIVIDUAL CALIBRATION(S)
  • ASH701945C_M/NONE (SN: 620002301) from 2008-03-19 to 2008-06-17, from 2008-06-17 to 2008-09-02, from 2008-09-02 to 2008-09-22, from 2008-10-20 to 2011-03-07 :
  • JAVRINGANT_DM/NONE (SN: 00464) from 2011-03-07 to 2018-02-01, from 2018-02-01 to 2021-04-20 :
DATA ROUTINELY ANALYSED BY BKG, LPT, NKG, ROB, SGO
INCLUSION IN OTHER NETWORK(S) IGS, EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 12-01-2021.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 011/2021 N/A
BEV 011/2021 N/A
BKGI 011/2021 N/A
RINEX V3.04 - GPS+GLO+GAL+BDS+QZSS+IRNSS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 276/2024 78.57%
BEV 282/2024 100%
BKGI 282/2024 100%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 283/2024 (R) 100% 98.21%
BKGI 283/2024 (R) 100% 100%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

Real-time

BRUX00BEL0 :

  • ASI (broadcaster, registration) - RTCM 3.3 : GPS+GLO+GAL+BDS+QZSS+SBAS (MSM7)

    2024/10/09 10:53 RTCM 3.3 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS+SBAS) wrt source table (GPS+GLO)

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

Location

Pictures
