RESPONSIBLE AGENCY IGE (Instituto Geografico Nacional de Espana)
RESPONSIBLE FOR METADATA IGE (Instituto Geografico Nacional de Espana)
CURRENT STATION CONFIGURATION cant00esp_20230725.log
STATUS IN EPN included since 21-01-2001
DATA LICENSE CC-BY-4.0
DIGITAL OBJECT IDENTIFIER (DOI) https://doi.org/10.24414/ROB-EUREF-CANT00ESP
LAST AVAILABLE DATA 01-07-2024
LAST RECEIVER LEICA GR10 (25-07-2023 to now)
SET TO TRACK GPS+GLO+GAL
LAST ANTENNA LEIAR25.R4/LEIT (20-10-2011 to now)
INDIVIDUAL CALIBRATION(S)
  • LEIAR25.R4/LEIT (SN: 725066) from 2011-10-20 to now :
DATA ROUTINELY ANALYSED BY ASI, IGE, IGN, ROB
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 02-12-2020.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 335/2020 N/A
BEV 316/2020 N/A
BKGE 335/2020 N/A
RINEX V3.04 - GPS+GLO+GAL
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 177/2024 71.43%
BEV 183/2024 92.86%
BKGE 183/2024 92.86%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 185/2024 (C) 30.36% 30.36%
BKGE 185/2024 (C) 100% 100%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

Real-time

CANT00ESP0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL (MSM5)

    2024/07/02 18:23 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL) wrt source table (GPS+GLO)

    2024/07/02 18:23 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.70.040) wrt site log (4.70/6.525)

    2024/07/02 18:23 RTCM 3.2/1006: Incorrect Antenna Height in stream (3.0490 m) wrt site log (3.20797 m)

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL (MSM5)

    2024/07/02 16:09 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.70.040) wrt site log (4.70/6.525)

    2024/07/02 16:09 RTCM 3.2/1006: Incorrect Antenna Height in stream (3.0490 m) wrt site log (3.20797 m)

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL (MSM5)

    2024/07/02 21:12 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.70.040) wrt site log (4.70/6.525)

    2024/07/02 21:12 RTCM 3.2/1006: Incorrect Antenna Height in stream (3.0490 m) wrt site log (3.20797 m)

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

Location

Pictures
