RESPONSIBLE AGENCY ROB (Royal Observatory of Belgium)
RESPONSIBLE FOR METADATA ROB (Royal Observatory of Belgium)
CURRENT STATION CONFIGURATION dent00bel_20230626.log
STATUS IN EPN included since 14-01-1996
LAST AVAILABLE DATA 19-04-2024
LAST RECEIVER SEPT POLARX5 (04-04-2023 to now)
SET TO TRACK GPS+GLO+GAL+BDS+QZSS
LAST ANTENNA TRM59800.00/NONE (23-06-2023 to now)
INDIVIDUAL CALIBRATION(S)
  • TRM59800.00/NONE (SN: 5131354230) from 2015-09-11 to 2018-04-25, from 2018-04-25 to 2018-06-01, from 2018-06-01 to 2023-06-23, from 2023-06-23 to now :
DATA ROUTINELY ANALYSED BY IGN, LPT, MUT, ROB
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 12-01-2021.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 011/2021 N/A
BEV 011/2021 N/A
BKGE 011/2021 N/A
RINEX V3.04 - GPS+GLO+GAL+BDS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 104/2024 78.57%
BEV 110/2024 100%
BKGE 110/2024 100%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 111/2024 (G) 100% 100%
BKGE 111/2024 (G) 100% 100%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

Real-time

DENT00BEL0 :

  • ASI (broadcaster, registration) - RTCM 3.3 : GPS+GLO+GAL+BDS+QZSS+SBAS (MSM7)

    2024/04/19 19:13 RTCM 3.3 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS+SBAS) wrt site log (GPS+GLO+GAL+BDS+QZSS)

    2024/04/19 19:13 RTCM 3.3 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS+SBAS) wrt source table (GPS+GLO)

    2024/04/19 19:13 RTCM 3.3/1006: Incorrect Antenna Height in stream (0.7650 m) wrt site log (0.85435 m)

  • BKG (broadcaster, registration) - RTCM 3.3 : GPS+GLO+GAL+BDS+QZSS+SBAS (MSM7)

    2024/04/19 17:01 RTCM 3.3 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS+SBAS) wrt site log (GPS+GLO+GAL+BDS+QZSS)

    2024/04/19 17:01 RTCM 3.3/1006: Incorrect Antenna Height in stream (0.7650 m) wrt site log (0.85435 m)

  • ROB (broadcaster, registration) - RTCM 3.3 : GPS+GLO+GAL+BDS+QZSS+SBAS (MSM7)

    2024/04/19 22:04 RTCM 3.3 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS+SBAS) wrt site log (GPS+GLO+GAL+BDS+QZSS)

    2024/04/19 22:04 RTCM 3.3/1006: Incorrect Antenna Height in stream (0.7650 m) wrt site log (0.85435 m)

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

Location

Pictures
