RESPONSIBLE FOR METADATA ASI (Agenzia Spaziale Italiana)
RESPONSIBLE AGENCY ASI (Agenzia Spaziale Italiana)
CURRENT STATION CONFIGURATION galh00ita_20220913.log
STATUS IN EPN included since 02-10-2022
LAST AVAILABLE DATA 28-01-2023
LAST RECEIVER LEICA GR30 (26-07-2018 to now)
SET TO TRACK GPS+GLO+GAL+BDS+QZSS+SBAS
LAST ANTENNA LEIAR20/NONE (24-05-2018 to now)
INDIVIDUAL CALIBRATION(S) none
DATA ROUTINELY ANALYSED BY ASI, BEK, SUT, UPA

The RINEX 2 data are no more submitted to the EPN data centres since 21-06-2022.

RINEX V2.11
Daily
(data calendar)

No recent data available

RINEX V3.03 - GPS+GLO+GAL+BDS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 022/2023 78.57%
BEV 028/2023 100%
BKGE 028/2023 100%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 029/2023 (H) 100% 94.05%
BKGE 029/2023 (H) 100% 94.05%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

Real-time

GALH00ITA0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2023/01/28 19:41 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2023/01/28 19:41 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO+GAL+BDS+SBAS)

    2023/01/28 19:41 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.20.232) wrt site log (4.20/7.300)

    2023/01/28 19:41 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 1.9398 m) exceeds threshold

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2023/01/28 17:27 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2023/01/28 17:27 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.20.232) wrt site log (4.20/7.300)

    2023/01/28 17:27 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 1.9398 m) exceeds threshold

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2023/01/28 22:31 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2023/01/28 22:31 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.20.232) wrt site log (4.20/7.300)

    2023/01/28 22:31 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 1.9398 m) exceeds threshold

information above extracted from monitor files - https://epncb.eu/ftp/station/real_time/

Location

Pictures
