RESPONSIBLE AGENCY AGH (AGH University of Science and Technology)
RESPONSIBLE FOR METADATA AGH (AGH University of Science and Technology)
CURRENT STATION CONFIGURATION kra100pol_20231023.log
STATUS IN EPN included since 21-03-2010
LAST AVAILABLE DATA 19-04-2024
LAST RECEIVER TRIMBLE ALLOY (23-10-2023 to now)
SET TO TRACK GPS+GLO+GAL+BDS
LAST ANTENNA TRM57971.00/NONE (29-01-2018 to now)
INDIVIDUAL CALIBRATION(S)
  • TRM57971.00/NONE (SN: 30607506) from 2018-01-29 to now :
DATA ROUTINELY ANALYSED BY BEV, MUT, RGA, SUT, WUT
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 24-05-2022.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 144/2022 N/A
BEV 144/2022 N/A
BKGE 084/2022 N/A
RINEX V3.05 - GPS+GLO+GAL+BDS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 104/2024 75%
BEV 110/2024 96.43%
BKGE 110/2024 96.43%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 111/2024 (G) 99.4% 99.4%
BKGE 111/2024 (G) 99.4% 98.81%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

Real-time

KRA100POL0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2024/04/19 21:40 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO)

    2024/04/19 21:40 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (6.20,31/JAN/2023) wrt site log (6.20)

    2024/04/19 21:40 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0001 m) wrt site log (0.06424 m)

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2024/04/19 19:36 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (6.20,31/JAN/2023) wrt site log (6.20)

    2024/04/19 19:36 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0001 m) wrt site log (0.06424 m)

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2024/04/20 00:45 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO)

    2024/04/20 00:45 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (6.20,31/JAN/2023) wrt site log (6.20)

    2024/04/20 00:45 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0001 m) wrt site log (0.06424 m)

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

Location

Pictures
