RESPONSIBLE AGENCY IGE (Instituto Geografico Nacional de Espana)
RESPONSIBLE FOR METADATA IGE (Instituto Geografico Nacional de Espana)
CURRENT STATION CONFIGURATION sala00esp_20240411.log
STATUS IN EPN included since 12-11-2006
DATA LICENSE CC-BY-4.0
DIGITAL OBJECT IDENTIFIER (DOI) https://doi.org/10.24414/ROB-EUREF-SALA00ESP
LAST AVAILABLE DATA 02-10-2024
LAST RECEIVER LEICA GR50 (11-04-2024 to now)
SET TO TRACK GPS+GLO+GAL+BDS
LAST ANTENNA LEIAR25/NONE (17-06-2009 to now)
INDIVIDUAL CALIBRATION(S) none
DATA ROUTINELY ANALYSED BY BEK, IGE, MUT, RGA
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 02-12-2020.

RINEX V2.11 - GPS+GLO+GAL
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 336/2020 N/A
BEV 316/2020 N/A
BKGE 335/2020 N/A
RINEX V3.04 - GPS+GLO+GAL+BDS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 270/2024 78.57%
BEV 276/2024 100%
BKGE 276/2024 100%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 277/2024 (L) 99.4% 97.02%
BKGE 277/2024 (K) 100% 98.21%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

Real-time

SALA00ESP0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2024/10/02 23:53 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO)

    2024/10/02 23:53 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.80.109) wrt site log (4.80/7.900)

    2024/10/02 23:53 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0600 m) wrt site log (0.21534 m)

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2024/10/02 22:11 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.80.109) wrt site log (4.80/7.900)

    2024/10/02 22:11 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0600 m) wrt site log (0.21534 m)

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2024/10/03 03:21 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.80.109) wrt site log (4.80/7.900)

    2024/10/03 03:21 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0600 m) wrt site log (0.21534 m)

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

Location

Pictures
