RESPONSIBLE AGENCY LMV (Lantmäteriet, the Swedish mapping, cadastral and land registration authority)
RESPONSIBLE FOR METADATA LMV (Lantmäteriet, the Swedish mapping, cadastral and land registration authority)
CURRENT STATION CONFIGURATION vis000swe_20221208.log
STATUS IN EPN included since 03-11-1996
LAST AVAILABLE DATA 19-04-2024
LAST RECEIVER SEPT POLARX5 (08-12-2022 to now)
SET TO TRACK GPS+GLO+GAL+BDS+SBAS
LAST ANTENNA AOAD/M_T/OSOD (08-11-1996 to now)
INDIVIDUAL CALIBRATION(S) none
DATA ROUTINELY ANALYSED BY BEV, GFZ, MUT, NKG, WUT
INCLUSION IN OTHER NETWORK(S) IGS, EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 28-04-2020.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 118/2020 N/A
BEV 023/2020 N/A
BKGI 118/2020 N/A
RINEX V3.04 - GPS+GLO+GAL+BDS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 104/2024 75%
BEV 110/2024 96.43%
BKGI 110/2024 96.43%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 111/2024 (V) 100% 100%
BKGI 111/2024 (V) 100% 100%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

Real-time

VIS000SWE0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS+QZSS (MSM5)

    2024/04/20 03:16 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2024/04/20 03:16 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS) wrt source table (GPS+GLO+GAL+BDS)

    2024/04/20 03:16 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0710 m) wrt site log (0.16284 m)

    2024/04/20 03:16 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.0814 m) exceeds threshold

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS+QZSS (MSM5)

    2024/04/20 01:38 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2024/04/20 01:38 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0710 m) wrt site log (0.16284 m)

    2024/04/20 01:38 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.0814 m) exceeds threshold

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS+QZSS (MSM5)

    2024/04/20 06:40 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2024/04/20 06:40 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0710 m) wrt site log (0.16284 m)

    2024/04/20 06:40 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.0814 m) exceeds threshold

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

Location

Pictures
