RESPONSIBLE AGENCY RIGTC GOP (Research Institute of Geodesy, Topography and Cartography Geodetic Observatory Pecny)
RESPONSIBLE FOR METADATA GOP (Geodetic Observatory Pecny, RIGTC)
CURRENT STATION CONFIGURATION tubo00cze_20220502.log
STATUS IN EPN included since 23-09-2001
LAST AVAILABLE DATA 19-04-2024
LAST RECEIVER LEICA GR30 (02-05-2022 to now)
SET TO TRACK GPS+GLO+GAL+BDS+QZSS+SBAS
LAST ANTENNA LEIAR25.R4/LEIT (12-12-2011 to now)
INDIVIDUAL CALIBRATION(S)
  • LEIAR25.R4/LEIT (SN: 10401005) from 2011-12-12 to now :
  • LEIAT504/LEIS (SN: 102923) from 2005-12-15 to 2011-12-12 :
DATA ROUTINELY ANALYSED BY BEV, GFZ, RGA, SGO, SUT
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 16-03-2022.

RINEX V2.11 - GPS+GLO+GAL+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 074/2022 N/A
BEV 074/2022 N/A
BKGE 074/2022 N/A
RINEX V3.03 - GPS+GLO+GAL+BDS+QZSS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 104/2024 78.57%
BEV 110/2024 100%
BKGE 110/2024 100%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 111/2024 (F) 97.62% 97.02%
BKGE 111/2024 (F) 97.62% 97.02%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

Real-time

TUBO00CZE0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5) : stream temporarily unavailable

    2024/04/20 02:24 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2024/04/20 02:24 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO+GAL+BDS+QZSS)

    2024/04/20 02:24 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.52.518) wrt site log (4.52/7.111)

    2024/04/20 02:24 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.3113 m) wrt site log (0.47027 m)

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS+QZSS (MSM5) : stream temporarily unavailable

    2024/04/20 00:47 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2024/04/20 00:47 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.52.518) wrt site log (4.52/7.111)

    2024/04/20 00:47 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.3113 m) wrt site log (0.47027 m)

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS+QZSS (MSM5) : stream temporarily unavailable

    2024/04/20 05:49 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2024/04/20 05:49 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.52.518) wrt site log (4.52/7.111)

    2024/04/20 05:49 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.3113 m) wrt site log (0.47027 m)

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

Location

Pictures
